Introduction
The macaroni production line mainly use flour, starch as raw material. We are using unique extrusion process, many popular shapes in market, the rational design of the production line, There are fully automatic, precisely control system, the host with the high and low pressure screw, to increase the range of use of raw materials, to reduce the cost and improve the product quality. The main products are:
.Products
This line can be used to produce screw, shell, round tube, square tube, bend tube and so on.
Raw materials
Wheat flour.
Capacity
80-100kg/h
Machine material
All the machines are made by Stainless steel 201,If you have special requirement, we also have ss304,ss316.
Voltage
Chinese Input Voltage is 380V/ 50Hz /3, If it is different from yours , we will adjust it .
Process Flow
Mixer---screw conveyor---single screw extruder---cutting machine---cooling conveyor---roasting oven---cooling---(packing machine)
Technical parameter of macaroni production line
|
Model |
CYS-100 Single-screw extruder line |
|
Installed capacity |
55KW |
|
Power consumption |
40KW |
|
Output |
80-100kg/h |
|
Size |
18.0*1.2*2.0m |
Technical parameter of machine
|
NO |
Machine |
Motor Power |
Capacity |
Dimension |
Quantity |
Function |
|
1 |
Mixer |
4KW |
50kgs /once time |
0.8*0.7*1.5m |
1set |
To mix the raw materals with the water |
|
2 |
Screw conveyer |
1.1KW |
100-150kg/h |
3.0*0.8*2m |
1set |
To send the materials to the extruder |
|
3 |
CYS-100 Single screw extruder |
30KW |
80-100kg/h |
4.0*1.2*3.0 m |
1set |
To extrude the food.the main machine of the line |
|
4 |
Cutting machine |
1.1KW |
80-150kg/h |
2.4*0.6*1.3 |
1set |
To cut the macaroni to round tube or square tube |
|
5 |
Vibrate cooler |
0.75KW |
80-150kg/h |
1.0*0.8*1.3 |
set |
To cool and convey the macaroni |
|
6 |
5layers 8meter oven |
80-120kg/h |
8.0×1.4×2.5m |
1set |
To dry the macaroni |
|
|
7 |
Cooling machine |
1.2kw |
150-300kg/h |
6m lenth |
1set |
To cool the macaroni |
1. We can provide factory layout according to customer’s factory size in advance.
2. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the corn flakes processing line arrived your country, and we will send two engineers to go and help you to install the corn flakes line, teach your worker(3-4 workers) how to operate the corn flakes line, until your worker know the corn flakes line well.
3. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
4. Our engineers can provide basic formula for producing the corn flakes, breakfast cereals, snack food etc. and help customer to produce good quality food according customer’s detailed formula.
5. We provide the spare parts will at preferential price for an extended long time.
